Connection Handling with the MongoDB PHP driver

The 1.3 release series of the PHP MongoDB driver features a rewritten connection handling library. This is quite a large change and changes how the PHP driver deals with persistent connections and connection pooling.

Connections in the 1.2 series

The 1.2 release introduced connection pooling into the driver. This means that any time the driver needs to use a connection to run queries, it would request a connection from the pool. It would then later return the connection once it was done with it. Being done is defined as "the variable holding the connection object goes out of scope". To illustrate that, take for example the following scripts.

The simplest version:

<?php
$m = new MongoClient();    // ← connection is requested from the pool
$c = $m->demo->test;
$c->insert( array( 'test' => 'yes' ) );
?>
← connection is returned to the pool as $m goes out of scope

Inside a function:

<?php
function doQuery()
{
        $m = new MongoClient();    // ← connection is requested from the pool
        $c = $m->demo->test;
        $c->insert( array( 'test' => 'yes' ) );
} // ← connection is returned to the pool as $m goes out of scope
?>

Now, in a few cases, this can result in lots of connections being made. One common occurence is trying to use connections deep inside a model layer-which typically happens if you use ORMs/ODMs with complex structures having a link to your connection object. A simple variant of how this happens is:

<?php
for ( $i = 0; $i < 5; $i++ )
{
        $conns[] = new MongoClient();
        }
        // ← now we have 5 connections open
?>

Connections in the 1.3 series

In the 1.3 series the connection management is done different. Per worker process (thread or PHP-FPM or Apache worker) the driver now manages connections in the C-part of driver separately from the Mongo* objects. This greatly reduces complexity in the driver. Let's have a look at how the driver handles connection for a basic MongoDB setups with just one node.

Sad manager, it has no connections yet.

When a worker process starts up, the MongoDB driver instantiates a manager to manage your connections. By default of course, this manager is rather sad, as it contains no connections yet.

Upon the first request doing new MongoClient();, the driver creates a new connection, and with this connection it creates a hash to identify this connection. Parameters for this hash includes: the hostname and the port, the process ID (pid), if available the replica set name and in case of authenticated connections, the database name, the username and a hash of the password. We will come back to authenticated connections later. You can quite easily see which hash is created, by calling the MongoClient::getConnections() method:

<?php
$m = new MongoClient( 'mongodb://whisky:27017/' );
var_dump( $m->getConnections()[0]['hash'] );
?>

Which outputs:

string(22) "whisky:27017;-;X;22835"

The - in this output denotes that the connection does not belong to a replica set and the X in this output is a place holder in case no username, database and password are given. 22835 is the process ID of the running script.

This newly created connection is then registered with the manager:

One connection, to the whisky!

Any time a connection is needed, for either an insert, delete, update, find or command query, the driver asks the manager to find a fitting connection to perform this query. It uses the information from the arguments to new MongoClient() as well as the PID of the current process to find this connection. Because the manager has a connection list per worker process/thread, and PHP's workers all run one request at a time, there is no need to have more than one connection per host. The connection gets reused and reused until the PHP worker ends, or you close the connection forcefully with MongoClient::close().

Replica sets

In a replicaset environment, this works all a bit different. In the connection string to new MongoClient() you need to specify a few hosts, preferrably all that you are aware of, as well as an annotation that you are using a replica set, for example:

$m = new MongoClient("mongodb://whisky:13000,whisky:13001/?replicaSet=seta");

It is important that you specify the replicaSet argument, as without it the driver will assume you are connecting to three different mongos processes.

Upon instantiation, the driver will discover the replica set's topology. The following output shows that all visible data nodes of the replica set will have a connection registered in the manager after the new MongoClient() call:

<?php
$m = new MongoClient( 'mongodb://whisky:13001/?replicaSet=seta' );
foreach ( $m->getConnections() as $c )
{
	echo $c['hash'], "\n";
}
?>

Which outputs:

whisky:13001;seta;X;32315
whisky:13000;seta;X;32315

Notice that the connection string made no reference to the whisky:13000 node. The manager has now registered two connections:

More whisky!

The manager contains a bit more information than just the connection hash and the TCP/IP socket. It also knows which nodes are primary nodes, and how "far away" a specific node is. This script shows how to retrieve this additional information:

<?php
$m = new MongoClient( 'mongodb://whisky:13001/?replicaSet=seta' );
foreach ( $m->getConnections() as $c )
{
	echo $c['hash'], ":\n",
		" - {$c['connection']['connection_type_desc']}, ",
		"{$c['connection']['ping_ms']} ms\n";
}
?>

Which outputs:

whisky:13001;seta;X;5776:
 - SECONDARY, 1 ms
whisky:13000;seta;X;5776:
 - PRIMARY, 0 ms

The driver knows about two types of queries. Write queries, which involve insert, update, remove and commands, and read queries, which involves find and findOne. By default, the manager will always return a connection to a primary node, unless you use the new read preferences. I will be writing a separate post about read preferences, but the basic idea is that they can control from which replica set nodes data is read from. For now, we will only use the setSlaveOkay() equivalent directly in the connection string:

$m = new MongoClient("mongodb://whisky:13000,whisky:13001/?replicaSet=seta&readPreference=secondaryPreferred");

As you can see, this connection string is rather long, which is why the PHP driver also allows you to pass in an array of options as second argument:

$options = array(
        'replicaSet' => 'seta',
        'readPreference' => 'secondaryPreferred',
);
$m = new MongoClient("mongodb://whisky:13000,whisky:13001/", $options);

Per query, the driver will ask the manager for a fitting connection. For write queries, it will always pick a primary node, and for read queries it will pick a secondary node if they are available and not too "far away" (what that means, I'll again explain in my upcoming read preferences article).

Authenticated connections

If authentication is enabled on MongoDB, then the connection hash will start to include an authentication hash. This is to make sure that different scripts that use the same MongoDB server, but different user name/password/database combinations, do not inadvertently use a wrongly authenticated connection. Let's see what the hash turns into if we connect to the admin database with the admin user:

<?php
$m = new MongoClient( 'mongodb://admin:admin@whisky:27017/admin' );
var_dump( $m->getConnections()[0]['hash'] );
?>

Which outputs:

string(64) "whisky:27017;-;admin/admin/bda5cc70cd5c23f7ffa1fda978ecbd30;8697"

The X that we previously saw, has now been replaced by a string containing the database name admin, the user name admin and the hash bda5cc70cd5c23f7ffa1fda978ecbd30. This hash is created from the user name database and hashed password.

In order for authentication to work the driver needs to have the database name in the connection string (in our case admin), otherwise, it will default to admin.

To use a database after you have established a connection, need to select the database again though. For example when you want to run a query:

$collection = $m->demoDb->collection;
$collection->findOne();

If this database matches the database name in the connection string, or when the database name in the connection string was admin, everything is well. However, if the database name accessed as property of the connection object is different then the one specified in the connection string then the driver has to create a new connection to prevent leaking of authentication between multiple requests. The following example illustrates this:

<?php
$m = new MongoClient( 'mongodb://user:user@whisky:27017/test' );

$db = $m->test2;
$collection = $db->collection;
var_dump( $collection->findOne() );
?>

Which outputs:

Fatal error: Uncaught exception 'MongoCursorException' with message
'whisky:27017: unauthorized db:test2 ns:test2.collection lock type:0 client:127.0.0.1'
in …/mongo-connect-5.php.txt:6

This is of course we have not actually authenticated for the test2 database. If we authenticate, then it works (even though findOne() does not actually find anything), and we can see all the created connections:

<?php
$m = new MongoClient( 'mongodb://user:user@whisky:27017/test' );

$db = $m->test2;
$db->authenticate('user2', 'user2' );
$collection = $db->collection;
$collection->findOne();

foreach ( $m->getConnections() as $c )
{
	echo $c['hash'], "\n";
}
?>

Which outputs:

whisky:27017;-;test/user/602b672e2fdcda7b58a042aeeb034376;26983
whisky:27017;-;test2/user2/984b6b4fd6c33f49b73f026f8b47c0de;26983

And we have two authenticated connections in our manager:

Safe whisky!

But with one snag. If you have E_DEPRECATED notices turned on, you will see:

Deprecated: Function MongoDB::authenticate() is deprecated in …/mongo-connect-6.php.txt on line 5

The driver can do things much more optimised if you create two MongoClient objects instead:

<?php
$mTest1 = new MongoClient( 'mongodb://user:user@whisky:27017/test', array( 'connect' => false ) );
$mTest2 = new MongoClient( 'mongodb://user2:user2@whisky:27017/test2', array( 'connect' => false ) );

$mTest1->test->test->findOne();
$mTest2->test2->test->findOne();

foreach ( $mTest2->getConnections() as $c )
{
	echo $c['hash'], "\n";
}
?>

With this, I conclude this post on the MongoDB driver's new connection handling. In future posts I will write about the 1.3 release providing (a lot) better debugging information, read preference functionality, and the new aggregation framework that comes with MongoDB 2.2.
