Indexing Freeform-Tagged Data

At last week's MongoDB UK I presented on "Geolocation, Maps and MongoDB". During this talk I presented a few methods on how to store OpenStreetMap's tags on geographical objects. OpenStreetMap's tags are free form and for example for a road can look like:

alt_name:    The Strand
highway:     primary
name:        Strand
oneway:      yes
postal_code: WC2

For this article, I am using a data extra from OpenStreetMap for just London. There are about 2.2 million items in my database after importing taking up 413MB of storage (without indexes).

Tags as a normal object

The first method for storing into MongoDB basically uses a tags field with each of the OpenStreetMap tag taking up a property in the array:

"_id" : "w1572026939",
"type" : NumberLong(2),
"tags" : {
        "alt_name" : "The Strand",
        "highway" : "primary",
        "name" : "Strand",
        "oneway" : "yes",
        "postal_code" : "WC2"
},
"loc" : [ [ -0.125262, 51.5086046 ], …, [ -0.1270609, 51.5076398 ] ]

In order to make looking up tags and values faster, we will need to create some indexes. We would like to look for streets by name:

db.poi.ensureIndex( { 'tags.name': 1 } );
db.poi.find( { 'tags.name': 'Strand' } );

And also find roads and paths:

db.poi.ensureIndex( { 'tags.highway': 1 } );
db.poi.find( { 'tags.highway' : { $exists: 1 } } );

As you can see, for every tag that we want to search on we would have to create an index. More indexes make inserts, updates and deletes slower and MongoDB is also limited to 64 indexes per collection. In order to have an index on every tag we need to find another solution. Also note that the second query doesn't even use an index when you check it with calling explain().

Tags as key/value pairs

The second method I introduced was the one where instead of storing the tags as properties of the tags field, I stored objects containing a tag/tagvalue pair each:

"tags_indexed" : [
        { "k" : "alt_name", "v" : "The Strand" },
        { "k" : "highway", "v" : "primary" },
        { "k" : "name", "v" : "Strand" },
        { "k" : "oneway", "v" : "yes" },
        { "k" : "postal_code", "v" : "WC2" }
],

The index we then can create is:

db.poi.ensureIndex( { 'tags_indexed.k' : 1, 'tags_indexed.v' : 1 } );

To answer the same questions as above we have to rewrite the queries. To find all documents where the name is Strand we can not simply do:

db.poi.find( { 'tags_indexed.k' : 'name', 'tags_indexed.v' : 'Strand' } );

This query will find all documents where either the key is name or the value is Strand. This includes documents where there is an array element like { "k" : "name", "v" : "Strand" } in the tags_indexed array, but also every other document where there is one "k" : "name" and a "v" : "Strand" element, such as in:

{
        "_id" : ObjectId("4fe4c4b044670a41222088b5"),
        "tags_indexed" : [
                { "k" : "addr:housenumber", "v" : "79" },
                { "k" : "addr:postcode", "v" : "WC2R 0DW" },
                { "k" : "addr:street", "v" : "Strand" },
                { "k" : "building", "v" : "yes" },
                { "k" : "name", "v" : "Stamp Centre" }
        ]
}

In order to match only documents where there is one array element with both the "k" : "name" and "v" : "Strand" properties, you need to use $elemMatch:

db.poi.find( {
        'tags_indexed' : { $elemMatch: { 'k' : 'name', 'v' : 'Strand' } }
} );

Let's look at the explain output of both variants. In the first case (with 'name': 'Strand'), the explain output looks like:

> db.poi.find( { 'tags.name': 'Strand' } ).explain();
{
        "cursor" : "BtreeCursor tags.name_1",
        "nscanned" : 12,
        "nscannedObjects" : 12,
        "n" : 12,
        "millis" : 1,
        "nYields" : 0,
        "nChunkSkips" : 0,
        "isMultiKey" : false,
        "indexOnly" : false,
        "indexBounds" : {
                "tags.name" : [ [ "Strand", "Strand" ] ]
        }
}

And in the second case, the explain output looks like:

> db.poi.find( {
... 'tags_indexed' : { $elemMatch: { 'k' : 'name', 'v' : 'Strand' } }
... } ).explain();
{
        "cursor" : "BtreeCursor tags_indexed.k_1_tags_indexed.v_1",
        "nscanned" : 172145,
        "nscannedObjects" : 172145,
        "n" : 12,
        "millis" : 429,
        "nYields" : 0,
        "nChunkSkips" : 0,
        "isMultiKey" : true,
        "indexOnly" : false,
        "indexBounds" : {
                "tags_indexed.k" : [ [ "name", "name" ] ],
                "tags_indexed.v" : [ [ { "$minElement" : 1 }, { "$maxElement" : 1 } ] ]
        }
}



In the first case, 12 documents are scanned and found. But in the second case, the same 12 documents are returned, but 172145 documents are scanned. This is because at the moment, $elemMatch does not use the index fully and will only use the first part of the compound index1tags_indexed.k in our case.

In order to make index usage better, it therefore makes more sense to have the property with the highest cardinality to be the first key in the compound index. In my data-set, the cardinality of tags_indexed.v is (a lot) higher than tags_indexed.k:

> db.poi.distinct( 'tags_indexed.k' ).length;
1281
> db.poi.distinct( 'tags_indexed.v' ).length;
151581

So let's change the keys in the compound index around, and run the explain for the second query again:

> db.poi.dropIndex( 'tags_indexed.k_1_tags_indexed.v_1' );
> db.poi.ensureIndex( { 'tags_indexed.v' : 1, 'tags_indexed.k' : 1 } );

> db.poi.find( {
... 'tags_indexed' : { $elemMatch: { 'k' : 'name', 'v' : 'Strand' } }
... } ).explain();
{
        "cursor" : "BtreeCursor tags_indexed.v_1_tags_indexed.k_1",
        "nscanned" : 44,
        "nscannedObjects" : 44,
        "n" : 12,
        "millis" : 0,
        "nYields" : 0,
        "nChunkSkips" : 0,
        "isMultiKey" : true,
        "indexOnly" : false,
        "indexBounds" : {
                "tags_indexed.v" : [ [ "Strand", "Strand" ] ],
                "tags_indexed.k" : [ [ { "$minElement" : 1 }, { "$maxElement" : 1 } ] ]
        }
}

Now with the higher cardinality on the first part of the compound key only 44 documents are scanned. And instead of 429 milliseconds it now took less than 1 millisecond. Excellent news!

The second question from the first section ("find roads and paths") can be rewritten as:

db.poi.find( { 'tags_indexed.k': 'highway' } );

However, this query can not be serviced by our rewritten index ('tags_indexed.v' : 1, 'tags_indexed.k' : 1) as MongoDB can only use keys starting from the left side of a compound index for queries. We can now either add another index that only encompasses the k part or perhaps find a different solution.

Tag keys and values combined

There is one other alternative that I would like to explore, and that is where I combine the key and value of each tag into one string, and store those all in an array in the object, like:

"tags_combined" : [
        "alt_name=The Strand",
        "highway=primary",
        "name=Strand",
        "oneway=yes",
        "postal_code=WC2"
],

And then we index this as:

db.poi.ensureIndex( { 'tags_combined': 1 } );

The first query we used earlier in this article ("all items where the name is Strand") now looks like:

> db.poi.find( { 'tags_combined': "name=Strand" ).explain();
{
        "cursor" : "BtreeCursor tags_combined_1",
        "nscanned" : 12,
        "nscannedObjects" : 12,
        "n" : 12,
        "millis" : 0,
        "nYields" : 0,
        "nChunkSkips" : 0,
        "isMultiKey" : true,
        "indexOnly" : false,
        "indexBounds" : {
                "tags_combined" : [ [ "name=Strand", "name=Strand" ] ]
        }
}

As you can see the index is very good at resolving this case, as it only scanned the 12 documents that the query also returned—just like where we had a direct index on tags.name.

The second query (all paths and roads) and its explain syntax are:

> db.poi.find( { 'tags_combined': /^highway=/ } ).explain();
{
        "cursor" : "BtreeCursor tags_combined_1 multi",
        "nscanned" : 210441,
        "nscannedObjects" : 210440,
        "n" : 210440,
        "millis" : 741,
        "nYields" : 0,
        "nChunkSkips" : 0,
        "isMultiKey" : true,
        "indexOnly" : false,
        "indexBounds" : {
                "tags_combined" : [
                        [ "highway=", "highway>" ], [ /^highway=/, /^highway=/ ]
                ]
        }
}

Here we use a regular expression search (/^highway=/) anchored to the start of the string (with the ^). This can use an index, and is almost as good as the the case where tags_indexed.k was the first part of the compound key, except that it is a bit slower (527 vs 741 milliseconds):

> db.poi.find( { 'tags_indexed.k': 'highway' } ).explain();
{
        "cursor" : "BtreeCursor tags_indexed.k_1_tags_indexed.v_1",
        "nscanned" : 210440,
        "nscannedObjects" : 210440,
        "n" : 210440,
        "millis" : 527,
        "nYields" : 0,
        "nChunkSkips" : 0,
        "isMultiKey" : true,
        "indexOnly" : false,
        "indexBounds" : {
                "tags_indexed.k" : [ [ "highway", "highway" ] ],
                "tags_indexed.v" : [ [ { "$minElement" : 1 }, { "$maxElement" : 1 } ] ]
        }
}

Conclusion

Right now, I think that having an indexed on tags_combined where each tag is combined with key and value and an array element tags_combined is the best solution. Its index scanning is better for the name=Strand case than the other, and not significantly slower in the highway=* case. I would still like to see how the speed differences progress when I add more objects to the database.

Shortlink

This article has a short URL available: http://drck.me/freetagidx-9gm

Comments

The combined tags and values approach is the approach I use in my music database (after trying the other approaches).

I store each tag twice, once as 'tag:value' and once as just the value; that way I can also search for a value in any field (artist, album, genre, word,...). I also split every tag up into individual words and add them to the tag array as 'word:value' so I can find words that aren't at the start of the string (without having to use a RegEx search).

Good article.

Nice post. But with any of this new structures, I can't see how to use sort() to order the results by "alt_name" for example ...

Can you give an example ?

Cordially.
